Antigen/Epitope Retrieval in Immunohistochemistry (IHC)

1. What is antigen retrieval? Why antigen retrieval in Immunohistochemistry is needed？

Antigen retrieval is a vital technique in immunohistochemistry (IHC) that enhances the visibility of antigens in formalin-fixed, paraffin-embedded (FFPE) tissue samples. During fixation, formaldehyde creates cross-links that mask epitopes—the specific regions of antigens recognized by antibodies. This masking impairs antibody access to these critical sites, limiting effective binding and impacting staining results. In professional IHC services, optimized antigen retrieval conditions are applied as part of a standardized workflow to ensure consistent, interpretable staining across FFPE tissue samples.

To address this, antigen retrieval methods are employed to reverse the cross-linking and restore antigenicity. These techniques allow antibodies to bind more effectively to their target antigens, improving sensitivity and accuracy in detection. While fixation is essential for preserving tissue morphology, it can negatively affect protein biochemistry, altering the conformation or electrostatic charge of epitopes and further hindering antibody interaction. Thus, antigen retrieval is necessary to ensure reliable diagnostic and research outcomes by overcoming the challenges posed by the fixation process.

Methods for antigen retrieval

Heat-Induced Epitope Retrieval (HIER)

HIER is the most widely used technique for antigen retrieval. This method utilizes heat to reverse the cross-linking that occurs during tissue fixation. Typically, tissue samples are immersed in a buffer solution, such as sodium citrate or EDTA, and subjected to heating using a microwave, pressure cooker, or water bath. The heat denatures proteins and breaks the cross-links, effectively unmasking the epitopes and allowing antibodies to bind more efficiently.

Microwave heat retrieval is highly effective for most antigens. It works in two ways: microwave radiation induces polar movement in molecules, aiding in the breakdown of aldehyde bonds. The rapid heat generated by this molecular motion, upon reaching a sufficient temperature, can denature proteins fixed with formaldehyde. This technique is known for its quick heat generation, simplicity of use, and the possibility of causing the antigen retrieval solution to boil.

Critical factors in HIER include the temperature, pH, and incubation time, all of which must be carefully optimized to ensure proper antigen unmasking without causing morphological damage. Common buffers used in HIER include sodium citrate (10 mM, pH 6), EDTA (1 mM, pH 8), and Tris/EDTA (pH 9), with temperatures typically reaching 95-100 °C.

Proteolysis-Induced Epitope Retrieval (PIER)

In contrast to HIER, PIER employs proteolytic enzymes, such as bromelain, aspronase, pepsin, ficin, trypsin, proteinase K, or other proteases, to digest the proteins surrounding the epitopes. This enzymatic treatment selectively breaks down specific protein structures, thereby exposing the masked epitopes. PIER is often considered a gentler approach compared to HIER, making it suitable for fragile tissues. However, careful optimization of enzyme concentration, incubation temperature, and incubation time is required to achieve optimal results.

Choosing the appropriate proteolytic enzymes depends on the specific antigen components being targeted. Typically, pepsin and bromelain are used to detect interstitial antigens like fibronectin, laminin (LN), and various types of collagen. Other proteolytic enzymes can be used to identify intracellular antigens. It's crucial to consider the optimal pH for each enzyme to ensure effective digestion.

Heat-induced Epitope Retrieval (HIER) vs Proteolytic-induced Epitope Retrieval (PIER)

Selecting Buffers for Heat-Induced Epitope Retrieval (HIER)

The pH of the retrieval solution used in antigen heat retrieval can significantly impact staining results. The effects of pH on staining can generally be classified into four categories:

1. Stable Type: pH has minimal effect on staining results, as seen with PCNA, AE1, EMA, and CD20.

2. V Type: Both high and low pH values yield good staining results, while pH values around 4-5 result in poorer staining, as observed with ER and Ki-67.

3. Increasing Type: Staining results improve progressively with increasing pH, such as with HMB45.

4. Decreasing Type: Staining results weaken as pH increases; this is rare and seen with antibodies like MOC31.

Currently, the most commonly used retrieval solutions are citrate buffer and EDTA buffer. Studies indicate that for most antibodies, EDTA (pH 8.0 or 9.0) is more effective than citrate at pH 6.0, especially for nuclear-positive antibodies. However, due to traditional practices, most hospitals and laboratories continue to use citrate buffer at pH 6.0.

IHC Antigen Retrieval Protocol

Optimal retrieval conditions depend on the type of tissue, fixation, and antibody, necessitating optimization for each antigen. To optimize antigen retrieval, preliminary studies should be conducted using a matrix of various combinations of time, temperature, and pH.

Here is an example of a matrix.

Microwave Heat Retrieval as an Example

Microwave heat retrieval is a commonly used Heat-Induced Epitope Retrieval (HIER) method. The following protocol uses it as an example. Optimal conditions always have to be determined by each laboratory and in accordance with the specific product information.

Materials:

• Microwave
• staining dish
• Antigen retrieval buffer (Tris/EDTA pH 9.0, sodium citrate pH 6.0, EDTA pH 8.0, or other)

Steps:

1.Immerse the slides in staining dish containing antigen retrieval buffer.

2.Microwave the staining dish at 95°C for 8 minutes.

3.Cool the slides for 5 minutes.

4.Microwave the staining dish at 95°C for 4 minutes.

5.Cool the slides to room temperature before proceeding with staining.

Note: Steamer, water bath or pressure cooker can be used as alternative heating source to replace microwave.

Proteolysis-Induced Epitope Retrieval (PIER)

PIER requires careful optimization of enzyme concentration, incubation temperature, and incubation time to achieve optimal results. Trypsin is a commonly used enzymatic antigen retrieval solution. The following protocol uses 0.1% trypsin as an example. Optimal conditions always have to be determined by each laboratory and in accordance with the specific product information.

Materials and reagents

37°C incubator

Humidified chamber

Enzymatic antigen retrieval solution

1.Prepare the 0.1% trypsin solution and preheat it to 37°C.

2. Pipette the enzyme solution onto the tissue section.

3. Place the slides in a humidified container and then into a 37°C incubator.

4. After 10-30 minutes, remove the slides and transfer them to a rack in a container of tap water.

5. Rinse under running water for 3 minutes.

6. Proceed with the immunohistochemical staining.
