Anti-Cathepsin D/CTSD Antibody Picoband™

Product Name

Anti-Cathepsin D/CTSD Antibody Picoband™

View all Cathepsin D Antibodies

SKU/Catalog Number

PB9048

Size

100 μg/vial

Form

Lyophilized

Description

Boster Bio Anti-Cathepsin D/CTSD Antibody Picoband™ catalog # PB9048. Tested in IF, IHC, ICC, WB applications. This antibody reacts with Mouse, Rat.

Storage & Handling

Store at -20˚C for one year from date of receipt. After reconstitution, at 4˚C for one month. It can also be aliquotted and stored frozen at -20˚C for six months. Avoid repeated freeze-thaw cycles.

Cite This Product

Anti-Cathepsin D/CTSD Antibody Picoband™ (Boster Biological Technology, Pleasanton CA, USA, Catalog # PB9048)

Host

Rabbit

Contents

Each vial contains 5mg BSA, 0.9mg NaCl, 0.2mg Na2HPO4, 0.05mg NaN3.

Clonality

Polyclonal

Isotype

Rabbit IgG

Immunogen

E.coli-derived mouse Cathepsin D recombinant protein (Position: E65-L410). Mouse Cathepsin D shares 85% and 91% amino acid (aa) sequences identity with human and rat Cathepsin D, respectively.

*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.

Cross-reactivity

No cross-reactivity with other proteins

Reactive Species

PB9048 is reactive to CTSD in Mouse, Rat

Applications

PB9048 is guaranteed for IF, IHC, ICC, WB Boster Guarantee

Observed Molecular Weight

45 kDa

Calculated molecular weight

44.552kDa

Background of Cathepsin D

Cathepsin D is a protein that in humans is encoded by the CTSD gene. This proteinase is a member of the peptidase C1 family, having a specificity similar to but narrower than that of pepsin A. It is mapped to 11p15.5. The cDNA encodes a 412-amino acid protein with 20 and 44 amino acids in a pre- and prosegment, respectively. Cathepsin D is one of the lysosomal proteinases. It is ubiquitously expressed and is involved in proteolytic degradation, cell invasion, and apoptosis. Mutations in this gene are involved in the pathogenesis of several diseases, including breast cancer and possibly Alzheimer disease and it has been considered as a breast cancer tumor marker.

Antibody Validation

Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.

View more details

Innovating Scientists Reward

If you are the first to review this product, or if you have results for a special sample, species or application this product is not validated in, share your results with us and receive product credits you can use towards any Boster products! Applicable to all scientists worldwide.

Submit A Review

Reconsitution

Add 0.2ml of distilled water will yield a concentration of 500ug/ml.

Assay Dilutions Recommendation

The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.

Western blot, 0.1-0.5μg/ml, Mouse
Immunohistochemistry (Paraffin-embedded Section), 0.5-1μg/ml, Mouse, Rat, By Heat
Immunocytochemistry/Immunofluorescence, 5 μg/ml, Mouse

Validation Images & Assay Conditions

Click image to see more details

Figure 1. IHC analysis of Cathepsin D using anti-Cathepsin D antibody (PB9048).
Cathepsin D was detected in paraffin-embedded section of Mouse Kidney Tissue. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Cathepsin D Antibody (PB9048) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

Click image to see more details

Figure 2. IHC analysis of Cathepsin D using anti-Cathepsin D antibody (PB9048).
Cathepsin D was detected in paraffin-embedded section of Mouse Liver Tissue. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Cathepsin D Antibody (PB9048) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

Click image to see more details

Figure 3. Western blot analysis of Cathepsin D using anti-Cathepsin D antibody (PB9048).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: Mouse Liver Tissue Lysate
Lane 2: Mouse Brain Tissue Lysate
Lane 3: Mouse Thymus Tissue Lysate
Lane 4: NEURO Whole Cell Lysate
After Electrophoresis, proteins were transferred to a Nitrocellulose membrane at 150mA for 50-90 minutes. Blocked the membrane with 5% Non-fat Milk/ TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-Cathepsin D antigen affinity purified polyclonal antibody (Catalog # PB9048) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for Cathepsin D at approximately 45KD. The expected band size for Cathepsin D is at 45KD.

Click image to see more details

Figure 4. IHC analysis of Cathepsin D using anti-Cathepsin D antibody (PB9048).
Cathepsin D was detected in paraffin-embedded section of rat liver tissues. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Cathepsin D Antibody (PB9048) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

Gene/Protein Information For CTSD (Source: Uniprot.org, NCBI)

Alternative Names

cathepsin D (lysosomal aspartyl protease); Cathepsin D; CPSD; CTSD; EC 3.4.23; EC 3.4.23.5; lysosomal aspartyl peptidase; lysosomal aspartyl protease; MGC2311; neuronal 10 CTSD CLN10, CPSD, HEL-S-130P cathepsin D cathepsin D|ceroid-lipofuscinosis, neuronal 10|epididymis secretory sperm binding protein Li 130P|lysosomal aspartyl peptidase|lysosomal aspartyl protease

For more info on CTSD, check out the CTSD Infographic

We have 30,000+ of these available, one for each gene! Check them out.

In this infographic, you will see the following information for CTSD: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].

Take me to the CTSD Infographic
