Pack Size:100μg/vial
Validated Species:Human
Application:IHC, ICC, WB
Data & Images


Product Name Anti-NOX5 Antibody
SKU/Catalog Number PA1947
Description Rabbit IgG polyclonal antibody for NADPH oxidase 5(NOX5) detection. Tested with WB, IHC-P, ICC in Human.
Cite This Product Anti-NOX5 Antibody (Boster Biological Technology, Pleasanton CA, USA, Catalog # PA1947)
Replacement Item This antibody may replace the following items: sc-34707|sc-67006 from Santa Cruz Biotechnology.
Host Rabbit
Isotype N/A
Validated Species Human
Application IHC, ICC, WB

*Our Boster Guarantee covers the use of this product in the above tested applications.

**For positive and negative control design, consult "Tissue specificity" under Protein Target Info.

Recommended Detection Systems Boster recommends Enhanced Chemiluminescent Kit with anti-Rabbit IgG (EK1002) for Western blot, and HRP Conjugated anti-Rabbit IgG Super Vision Assay Kit (SV0002-1) for IHC(P) and ICC.
*Blocking peptide can be purchased at $50. Contact us for more information
**Boster also offers various secondary antibodies for Immunoflourescecne and IHC. Take advantage of the buy 1 primary antibody get 1 secondary antibody for free promotion for the entire year 2018!
Immunogen A synthetic peptide corresponding to a sequence at the C-terminus of human NOX5(747-765aa KVLKGHCEKFGFRFFQENF).
Cross Reactivity No cross reactivity with other proteins
Pack Size 100μg/vial


Clonality Polyclonal
Form Lyophilized
Contents Each vial contains 5mg BSA, 0.9mg NaCl, 0.2mg Na2HPO4, 0.05mg Thimerosal, 0.05mg NaN3.
Concentration Add 0.2ml of distilled water will yield a concentration of 500ug/ml.
Storage At -20°C for one year. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for a longer time.Avoid repeated freezing and thawing.
Purification Immunogen affinity purified.
Isotype N/A

Protein Target Info (Source:

You can check the tissue specificity below for information on selecting positive and negative control.

Gene Name NOX5
Protein Name NADPH oxidase 5
Molecular Weight 86439 MW
Protein Function Calcium-dependent NADPH oxidase that generates superoxide. Also functions as a calcium-dependent proton channel and may regulate redox-dependent processes in lymphocytes and spermatozoa. May play a role in cell growth and apoptosis. Isoform v2 and isoform v5 are involved in endothelial generation of reactive oxygen species (ROS), proliferation and angiogenesis and contribute to endothelial response to thrombin. .
Tissue Specificity Mainly expressed in pachytene spermatocytes of testis and in lymphocyte-rich areas of spleen and lymph nodes. Isoform v1 is expressed in spleen. Isoform v2 is expressed in testis. Also detected in ovary, placenta, pancreas, cardiac fibroblasts. Expressed in B-cells and prostate malignant cells. Isoform v1 and isoform v3 are expressed in epithelial colorectal adenocarcinoma cells. Isoform v2 and isoform v4 are expressed in endothelial cells. Isoform v1, isoform v2, isoform v3 and isoform v4 are expressed in pulmonary artery smooth muscle cells. Isoform v2 and isoform v5 are expressed in microvascular endothelial cells (at protein level). .
Sequence Similarities Contains 4 EF-hand domains.
Subcellular Localization Membrane ; Multi-pass membrane protein .
Uniprot ID Q96PH1
Alternative Names NADPH oxidase 5;1.6.3.-;NOX5;
Research Areas |cell biology|apoptosis|intracellular|associated proteins| signal transduction|metabolism|plasma membrane|channels| cell biology|cell cycle|cell differentiation|other antibodies|oxidative stress| metabolism|pathways and processes|redox metabolism|
*if product is indicated to react with multiple species, protein info is based on the human gene.

Background for NADPH oxidase 5

NOX5(Nadph Oxidase 5), also known as NOX5A or NOX5B, is a protein which in humans is encoded by the NOX5 gene. The International Radiation Hybrid Mapping Consortium mapped the NOX5 gene to chromosome 15. NOX5 is a novel NADPH oxidase that generates superoxide and functions as an H+ channel in a Ca2+-dependent manner. Banfi et al.(2001) found that, when heterologously expressed, NOX5 was quiescent in unstimulated cells. However, in response to elevations of the cytosolic Ca2+ concentration, it generated large amounts of superoxide. Using RT-PCR and Southern and Western blot analyses, Kamiguti et al.(2005) identified NOX5 as a flavin-containing Ca2+-dependent oxidase present in hairy leukemic cells(HC), but not normal B cells.

Anti-NOX5 Antibody Images

Click the images to enlarge.

Anti-NOX5 Antibody
Anti-NOX5 antibody, PA1947, IHC(P)
IHC(P): Human Mammary Cancer Tissue
Anti-NOX5 Antibody
Anti-NOX5 antibody, PA1947, ICC
Anti-NOX5 Antibody
Anti-NOX5 antibody, PA1947, Western blotting
All lanes: Anti (PA1947) at 0.5ug/ml
Lane 1: 22RV1 Whole Cell Lysate at 40ug
Lane 2: PANC Whole Cell Lysate at 40ug
Lane 3: HELA Whole Cell Lysate at 40ug
Lane 4: SKOV Whole Cell Lysate at 40ug
Predicted bind size: 86KD
Observed bind size: 86KD
Write a review for PA1947


Jafari N1, Kim H1,2, Park R1,2, Li L1, Jang M1,2, Morris AJ3, Park J1,2, Huang C PLoS One. 2017 Jan 18;12(1):e0170327. doi: 10.1371/journal.pone.0170327. eCollection 2017. CRISPR-Cas9 Mediated NOX4 Knockout Inhibits Cell Proliferation and Invasion in HeLa Cells.

Customer Q&As

Q: Do you offer BSA-free antibodies? Keyword: Bovine serum albumin, carrier protein, conjugation
A: Yes, please contact us at for more information about BSA-free antibodies and availability. The new BSA-free formula uses trehalose as a replacement to BSA. We have tested many alternative chemicals and found that trehalose protects the antibodies the best.
Q: Is your western blot protocol provided from the website applicable for all your antibodies? Keyword: applications, WB
A: The protocol is applicable for all our antibodies in WB, the NC Membrane(0.45μm or 0.22μm) and transfer time(70 mins or 50 mins) depends on the protein molecular weight, details can be found in included protocol.
Q: Can I conjugate markers to this antibody? Can I link custom conjugates to this antibody? Keyword: conjugation
A: The antibody is stored with BSA and cannot be conjugated with markers. Carrier free antibodies are available upon request. Please contact
Q: What should I use for negative control?
A: Please contact us for negative control suggestions. You can also check expression databases such as genecards, uniprot etc. Due to logistic reasons, we do not sell serum or lysates that we use internally for positive or negative control.
Q: Where can I find troubleshooting information? What should I do if I have unexpected bands, high background, no signal, weak signal
A: You can find Boster's troubleshoot guides under tech support tab. Please contact us for further assistance on troubleshooting your experiment.
Q: What is the immunogen sequence of this antibody? Is this antibody polyclonal or monoclonal?
A: You can find the immunogen sequence under "Immunogen" and clonality in the product name.
Q: What is the expected band size? Why is it different than the observed band size?
A: The expected band size is predicted on the size of the protein. The actual band size may be affected by a few other factors including but not limited to:
1. Post-translational modification:phosphorylation, methylation, glycosylation etc. These modifications prevent SDS molecules from binding to the target protein and thus make the band size appear larger than expected
2. Post-translational cleavage: this can cause smaller bands and or multiple bands

3. Alternative splicing: the same gene can have alternative splicing patterns generating different size proteins, all with reactivities to the antibody.

4. Amino Acid R chain charge: SDS binds to positive charges. The different size and charge of the Amino Acid side chains can affect the amount of SDS binding and thus affect the observed band size.
5. Multimers: Multimers are usually broken up in reducing conditions. However if the interactions between the multimers are strong, the band may appear higher.,
Q: What is the suggested dilution ratio for Western Blot (WB), Immunohistochemistry (IHC) and or ELISA standards? What is the optimal pH for the sample?
A: Check the datasheet for the product for details on dilution ratios for different experiments. You can find the datasheet button on the right side of the product page.
Q: What is the protocol you used for your Western blotting (WB) and Immunohistochemistry (IHC)?
A: Check our protocols under the tech support tab.
