Anti-CD13/ANPEP Antibody Picoband™ (monoclonal, 7F2)

Product Name

Anti-CD13/ANPEP Antibody Picoband™ (monoclonal, 7F2)

View all Aminopeptidase N/CD13 Antibodies

SKU/Catalog Number

M02591-5

Size

100 μg/vial

Form

Lyophilized

Description

Boster Bio Anti-CD13/ANPEP Antibody Picoband™ (monoclonal, 7F2) catalog # M02591-5. Tested in IHC, WB applications. This antibody reacts with Human, Rat, Monkey.

Storage & Handling

At -20°C for one year from date of receipt. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months. Avoid repeated freezing and thawing.

Cite This Product

Anti-CD13/ANPEP Antibody Picoband™ (monoclonal, 7F2) (Boster Biological Technology, Pleasanton CA, USA, Catalog # M02591-5)

Host

Mouse

Contents

Each vial contains 4 mg Trehalose, 0.9 mg NaCl and 0.2 mg Na2HPO4.

Clonality

Monoclonal

Clone Number

7F2

Isotype

Mouse IgG1

Immunogen

E.coli-derived human CD13/ANPEP recombinant protein (Position: D148-S966).

*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.

Cross-reactivity

No cross-reactivity with other proteins.

Reactive Species

M02591-5 is reactive to ANPEP in Human, Monkey, Rat

Applications

M02591-5 is guaranteed for IHC, WB Boster Guarantee

Observed Molecular Weight

150 kDa

Calculated molecular weight

109.54kDa

Background of Aminopeptidase N/CD13

Membrane alanyl aminopeptidase (EC 3.4.11.2) also known as alanyl aminopeptidase (AAP) or aminopeptidase N (AP-N) is an enzyme that in humans is encoded by the ANPEP gene. It is mapped to 15q26.1. Aminopeptidase N is located in the small-intestinal and renal microvillar membrane, and also in other plasma membranes. In the small intestine aminopeptidase N plays a role in the final digestion of peptides generated from hydrolysis of proteins by gastric and pancreatic proteases. Its function in proximal tubular epithelial cells and other cell types is less clear. The large extracellular carboxyterminal domain contains a pentapeptide consensus sequence characteristic of members of the zinc-binding metalloproteinase superfamily. Sequence comparisons with known enzymes of this class showed that CD13 and aminopeptidase N are identical. The latter enzyme was thought to be involved in the metabolism of regulatory peptides by diverse cell types, including small intestinal and renal tubular epithelial cells, macrophages, granulocytes, and synaptic membranes from the CNS. Human aminopeptidase N is a receptor for one strain of human coronavirus that is an important cause of upper respiratory tract infections. Defects in this gene appear to be a cause of various types of leukemia or lymphoma.

Antibody Validation

Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.

View more details

Innovating Scientists Reward

If you are the first to review this product, or if you have results for a special sample, species or application this product is not validated in, share your results with us and receive product credits you can use towards any Boster products! Applicable to all scientists worldwide.

Submit A Review

Reconsitution

Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.

Assay Dilutions Recommendation

The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.

Western blot, 0.25-0.5 μg/ml, Rat, Monkey
Immunohistochemistry(Paraffin-embedded Section), 2-5 μg/ml, Human, Rat

Validation Images & Assay Conditions

Click image to see more details

Figure 1. Western blot analysis of CD13/ANPEP using anti-CD13/ANPEP antibody (M02591-5).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: monkey kidney tissue lysates,
Lane 2: rat kidney tissue lysates,
Lane 3: rat liver tissue lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with mouse anti-CD13/ANPEP antigen affinity purified monoclonal antibody (Catalog # M02591-5) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-mouse IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1001) with Tanon 5200 system. A specific band was detected for CD13/ANPEP at approximately 150 kDa. The expected band size for CD13/ANPEP is at 150 kDa.

Click image to see more details

Figure 2. IHC analysis of CD13/ANPEP using anti-CD13/ANPEP antibody (M02591-5).
CD13/ANPEP was detected in a paraffin-embedded section of human gallbladder adenocarcinoma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-CD13/ANPEP Antibody (M02591-5) overnight at 4°C. Biotinylated goat anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

Click image to see more details

Figure 3. IHC analysis of CD13/ANPEP using anti-CD13/ANPEP antibody (M02591-5).
CD13/ANPEP was detected in a paraffin-embedded section of human ovarian serous adenocarcinoma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-CD13/ANPEP Antibody (M02591-5) overnight at 4°C. Biotinylated goat anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

Click image to see more details

Figure 4. IHC analysis of CD13/ANPEP using anti-CD13/ANPEP antibody (M02591-5).
CD13/ANPEP was detected in a paraffin-embedded section of human renal clear cell carcinoma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-CD13/ANPEP Antibody (M02591-5) overnight at 4°C. Biotinylated goat anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

Click image to see more details

Figure 5. IHC analysis of CD13/ANPEP using anti-CD13/ANPEP antibody (M02591-5).
CD13/ANPEP was detected in a paraffin-embedded section of rat intestine tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-CD13/ANPEP Antibody (M02591-5) overnight at 4°C. Biotinylated goat anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1021) with DAB as the chromogen.

Gene/Protein Information For ANPEP (Source: Uniprot.org, NCBI)

Alternative Names

alanyl (membrane) aminopeptidase; Alanyl aminopeptidase; Aminopeptidase M; Aminopeptidase N; ANPEP; AP-M; APN; AP-N; CD13 antigen; CD13; CD13APN; EC 3.4.11; EC 3.4.11.2; gp150; LAP1; Microsomal aminopeptidase; Myeloid plasma membrane glycoprotein CD13; p150; PEPN; PEPNhAPN ANPEP APN, CD13, GP150, LAP1, P150, PEPN alanyl aminopeptidase, membrane aminopeptidase N|AP-M|AP-N|alanyl (membrane) aminopeptidase|aminopeptidase M|hAPN|membrane alanyl aminopeptidase|microsomal aminopeptidase|myeloid plasma membrane glycoprotein CD13

For more info on ANPEP, check out the ANPEP Infographic

We have 30,000+ of these available, one for each gene! Check them out.

In this infographic, you will see the following information for ANPEP: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].

Take me to the ANPEP Infographic
