GRAP antibody (A09913-3) performs well in ELISA, Flow Cytometry, IHC, WB and shows reactivity with Human, Mouse.
- Validated for inter-lot consistency, specificity, and reproducibility
- Committed to quality since 1993
Filter:
Flow Cytometry analysis of Jurkat cells using anti-GRAP antibody (A09913-3).
Overlay histogram showing Jurkat cells stained with A09913-3 (Blue line). The cells were fixed with 4% paraformaldehyde and blocked with 10% normal goat serum. And then incubated with rabbit anti-GRAP Antibody (A09913-3, 1 μg/1x106 cells) for 30 min at 20°C. Fluoro488 conjugated goat anti-rabbit IgG (BA1127, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1 μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Overlay histogram showing Jurkat cells stained with A09913-3 (Blue line). The cells were fixed with 4% paraformaldehyde and blocked with 10% normal goat serum. And then incubated with rabbit anti-GRAP Antibody (A09913-3, 1 μg/1x106 cells) for 30 min at 20°C. Fluoro488 conjugated goat anti-rabbit IgG (BA1127, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1 μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Bundle Save
Anti-GRAP Antibody Picoband®
GRAP antibody
| Reactive Species | Host | Application |
|---|---|---|
| Human, Mouse | Rabbit | ELISA, Flow Cytometry, IHC, WB |
Tested Applications
GRAP antibody was positively detected by WB in:
human REH whole cell, human Jurkat whole cell, human THP-1 whole cell, human HepG2 whole cell, mouse spleen tissue, mouse thymus tissue
Suggested blocking solution with 5% non-fat milk or BSA; (*)Recommended protein loading: 20-40 ug per lane
GRAP antibody was positively detected by IHC in:
mouse thymus tissue
Use TE buffer pH 9.0 for antigen retrieval; (*) citrate buffer pH 6.0 is an alternative.
GRAP antibody was positively detected by FC in:
Jurkat cell
Recommend Dilution
Application
Dilution
Species
Western blot
0.25-0.5 μg/ml
Human, Mouse
Immunohistochemistry(Paraffin-embedded Section)
2-5 μg/ml
Mouse
Flow Cytometry (Fixed)
1-3 μg/1x106 cells
Human
ELISA
0.1-0.5 μg/ml
* It is recommended to optimize the amount of this reagent in each experimental system to achieve the best results.
Note: For flow cytometry (FCM), validated for fixed cells only. Not validated for FACS or surface flow cytometry using live cells.
Reactive Data
Filter:
Boster Guarantee:What is this?
WB
IHC
IF
ELISA
Human
Tested
Recommend
Mouse
Tested
Tested
Recommend
Recommend
Monkey
Predicted
Predicted
Predicted
Predicted
Rabbit
Predicted
Predicted
Predicted
Predicted
Product Information
Product Name
Anti-GRAP Antibody Picoband®
View all GRAP Antibodies
View all GRAP Antibodies
Form
Lyophilized
Uniprot
Gene ID
Storage & Handling
At -20°C for one year from date of receipt.
After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months.
Avoid repeated freezing and thawing.
Host
Rabbit
Contents
Each vial contains 4 mg Trehalose, 0.9 mg NaCl, 0.2 mg Na2HPO4.
Clonality
Polyclonal
Immunogen
E.coli-derived human GRAP recombinant protein (Position: D133-L217).
Reconstitution
Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.
Observed Molecular Weight
25 kDa
Calculated Molecular Weight
25.3 kDa
Background of GRAP
This gene encodes a member of the GRB2/Sem5/Drk family and functions as a cytoplasmic signaling protein which contains an SH2 domain flanked by two SH3 domains. The SH2 domain interacts with ligand-activated receptors for stem cell factor and erythropoietin, and facilitates the formation of a stable complex with the BCR-ABL oncoprotein. This protein also associates with the Ras guanine nucleotide exchange factor SOS1 (son of sevenless homolog 1) through its N-terminal SH3 domain. In general, it couples signals from receptor and cytoplasmic tyrosine kinases to the Ras signaling pathway.
Cite This Product
Anti-GRAP Antibody Picoband® (Boster Biological Technology, Pleasanton CA, USA, Catalog # A09913-3)
Antibody Homology Across Species
The results generated by this homology analysis tool for commonly used animal species are shown below. For unlisted species, please refer to the homology analysis between the immunogen sequence and the corresponding species.
A homology of ≥90% is recommended. Generally, higher homology indicates a greater potential for cross-species reactivity. However, protein expression levels may vary among different species, tissues, and cell types. Therefore, the homology analysis results are for reference only and do not guarantee antibody cross-reactivity or experimental performance.
Human
100%
High Homology
Monkey
99%
High Homology
Rabbit
92%
High Homology
Cow
86%
Moderate Homology
Sheep
85%
Moderate Homology
Dog
85%
Moderate Homology
Mouse
84%
Moderate Homology
Rat
82%
Moderate Homology
Zebrafish
52%
Low homology
Drosophila
38%
Low homology
Homology ≥ 90%High Homology
70% ≤ Homology < 90%Moderate Homology
Homology < 70%Low homology
Protocols
Western Blot protocol for GRAP antibody
Immunohistochemistry (IHC) protocol for GRAP antibody
Flow Cytometry (FC) protocol for GRAP antibody
Review
Have you used Anti-GRAP Antibody Picoband®?
Submit a review and receive $370 in product credits, a $185 Amazon gift card, or our carefully curated gift bundles.
Product Promise
We promise Anti-GRAP Antibody Picoband® performs excellently in relevant applications for ELISA, Flow Cytometry, IHC, WB. If it doesn't perform as promised, we will refund the product. Learn more
In stock
Order Product
A09913-3
Buy one primary antibody get one 0.5ml HRP or Biotin secondary antibody for free.
*Sample sizes are prepared on demand and will take extra lead time. (cannot be conjugated)
$370.00
Troubleshooting
Boster Guarantee
Guaranteed product quality
We promise all of our products perform as described in datasheets.
This product is for Research Use Only. Not for use in diagnostic procedures.
