Product Info Summary
SKU: | A07608-1 |
---|---|
Size: | 100 μg/vial |
Reactive Species: | Human |
Host: | Rabbit |
Application: | ELISA, Flow Cytometry, IF, IHC, ICC, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-PDE4DIP Antibody Picoband™
View all Myomegalin Antibodies
SKU/Catalog Number
A07608-1
Size
100 μg/vial
Form
Lyophilized
Description
Boster Bio Anti-PDE4DIP Antibody Picoband™ catalog # A07608-1. Tested in ELISA, Flow Cytometry, IF, IHC, ICC, WB applications. This antibody reacts with Human.
Storage & Handling
At -20°C for one year from date of receipt. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months. Avoid repeated freezing and thawing.
Cite This Product
Anti-PDE4DIP Antibody Picoband™ (Boster Biological Technology, Pleasanton CA, USA, Catalog # A07608-1)
Host
Rabbit
Contents
Each vial contains 4 mg Trehalose, 0.9 mg NaCl, 0.2 mg Na2HPO4.
Clonality
Polyclonal
Isotype
Rabbit IgG
Immunogen
E.coli-derived human PDE4DIP recombinant protein (Position: Q96-M1254).
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
A07608-1 is reactive to PDE4DIP in Human
Reconstitution
Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.
Observed Molecular Weight
150 kDa
Calculated molecular weight
157578 MW
Background of Myomegalin
Myomegalin, also known as phosphodiesterase 4D-interacting protein or cardiomyopathy-associated protein 2, is a protein that in humans is encoded by the PDE4DIP gene. The protein encoded by this gene serves to anchor phosphodiesterase 4D to the Golgi/centrosome region of the cell. Defects in this gene may be a cause of myeloproliferative disorder (MBD) associated with eosinophilia. Several transcript variants encoding different isoforms have been found for this gene.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
A07608-1 is guaranteed for ELISA, Flow Cytometry, IF, IHC, ICC, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.25-0.5 μg/ml, Human
Immunohistochemistry(Paraffin-embedded Section), 2-5 μg/ml, Human
Immunocytochemistry/Immunofluorescence, 5 μg/ml, Human
Flow Cytometry (Fixed), 1-3 μg/1x106 cells, Human
Direct ELISA, 0.1-0.5 μg/ml, Human
Positive Control
Validation Images & Assay Conditions
![a07608 1 pde4dip primary antibodies wb testing 1 a07608 1 pde4dip primary antibodies wb testing 1](https://www.bosterbio.com/media/catalog/product/a/0/a07608-1-pde4dip-primary-antibodies-wb-testing-1.jpg)
Click image to see more details
Figure 1. Western blot analysis of PDE4DIP using anti-PDE4DIP antibody (A07608-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human Hela whole cell lysates,
Lane 2: human HEK293 whole cell lysates,
Lane 3: human K562 whole cell lysates,
Lane 4: human U-87MG whole cell lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-PDE4DIP antigen affinity purified polyclonal antibody (Catalog # A07608-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for PDE4DIP at approximately 150 kDa. The expected band size for PDE4DIP is at 150 kDa.
![a07608 1 pde4dip primary antibodies ihc testing 2 a07608 1 pde4dip primary antibodies ihc testing 2](https://www.bosterbio.com/media/catalog/product/a/0/a07608-1-pde4dip-primary-antibodies-ihc-testing-2.jpg)
Click image to see more details
Figure 2. IHC analysis of PDE4DIP using anti-PDE4DIP antibody (A07608-1).
PDE4DIP was detected in a paraffin-embedded section of human colorectal cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml rabbit anti-PDE4DIP Antibody (A07608-1) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
![a07608 1 pde4dip primary antibodies ihc testing 3 a07608 1 pde4dip primary antibodies ihc testing 3](https://www.bosterbio.com/media/catalog/product/a/0/a07608-1-pde4dip-primary-antibodies-ihc-testing-3.jpg)
Click image to see more details
Figure 3. IHC analysis of PDE4DIP using anti-PDE4DIP antibody (A07608-1).
PDE4DIP was detected in a paraffin-embedded section of human placenta tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml rabbit anti-PDE4DIP Antibody (A07608-1) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
![a07608 1 pde4dip primary antibodies if testing 4 a07608 1 pde4dip primary antibodies if testing 4](https://www.bosterbio.com/media/catalog/product/a/0/a07608-1-pde4dip-primary-antibodies-if-testing-4.jpg)
Click image to see more details
Figure 4. IF analysis of PDE4DIP using anti-PDE4DIP antibody (A07608-1).
PDE4DIP was detected in an immunocytochemical section of MCF-7 cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 5 μg/mL rabbit anti-PDE4DIP Antibody (A07608-1) overnight at 4°C. DyLight®594 Conjugated Goat Anti-Rabbit IgG (BA1142) was used as secondary antibody at 1:100 dilution and incubated for 30 minutes at 37°C. The section was counterstained with DAPI. Visualize using a fluorescence microscope and filter sets appropriate for the label used.
![a07608 1 pde4dip primary antibodies fcm testing 5 a07608 1 pde4dip primary antibodies fcm testing 5](https://www.bosterbio.com/media/catalog/product/a/0/a07608-1-pde4dip-primary-antibodies-fcm-testing-5.png)
Click image to see more details
Figure 5. Flow Cytometry analysis of A549 cells using anti-PDE4DIP antibody (A07608-1).
Overlay histogram showing A549 cells stained with A07608-1 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-PDE4DIP Antibody (A07608-1, 1 μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1 μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Protein Target Info & Infographic
Gene/Protein Information For PDE4DIP (Source: Uniprot.org, NCBI)
Gene Name
PDE4DIP
Full Name
Myomegalin
Weight
157578 MW
Alternative Names
Cardiomyopathy-associated protein 2; CMYA2; DKFZp781J054; KIAA0454; KIAA0477; MGC75440; MMGLcardiomyopathy associated 2; myomegalin; phosphodiesterase 4D interacting protein; Phosphodiesterase 4D-interacting protein PDE4DIP CMYA2, MMGL phosphodiesterase 4D interacting protein myomegalin|cardiomyopathy-associated protein 2|myomegalin/phosphodiesterase 4D interacting protein variant 8
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on PDE4DIP, check out the PDE4DIP Infographic
![PDE4DIP infographic](/media/images/gene-infographic-example.jpg)
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for PDE4DIP: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
