Western blot analysis of Plzf/ZBTB16 using anti-Plzf/ZBTB16 antibody (PB9969).
Electrophoresis was performed on a 10% SDS-PAGE gel at 80V (Stacking gel) / 120V (Resolving gel) for 2 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human Ramos whole cell lysates,
Lane 2: human Hela whole cell lysates,
Lane 3: rat testis tissue lysates,
Lane 4: rat PC-12 whole cell lysates,
Lane 5: mouse testis tissue lysates,
Lane 6: mouse RAW264.7 whole cell lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-Plzf/ZBTB16 antigen affinity purified polyclonal antibody (PB9969) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal is developed using an ECL Plus Western Blotting Substrate (Catalog # AR1196-200) with Tanon 5200 system. A specific band was detected for Plzf/ZBTB16 at approximately 74 kDa. The expected band size for Plzf/ZBTB16 is at 74 kDa.
