TIMM23 antibody (A09218-1) performs well in IHC, WB and shows reactivity with Human, Mouse, Rat.
- Validated for inter-lot consistency, specificity, and reproducibility
- Committed to quality since 1993
- Over 2 Publications
Filter:
IHC analysis of TIMM23 using anti-TIMM23 antibody (A09218-1).
TIMM23 was detected in a paraffin-embedded section of human colon cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1:100 rabbit anti-TIMM23 Antibody (A09218-1) overnight at 4°C. Peroxidase Conjugated Goat Anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB as the chromogen.
TIMM23 was detected in a paraffin-embedded section of human colon cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1:100 rabbit anti-TIMM23 Antibody (A09218-1) overnight at 4°C. Peroxidase Conjugated Goat Anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB as the chromogen.
Bundle Save
Anti-TIM23/TIMM23 Antibody Picoband®
TIMM23 antibody
| Reactive Species | Host | Application |
|---|---|---|
| Human, Mouse, Rat | Rabbit | IHC, WB |
Tested Applications
TIMM23 antibody was positively detected by WB in:
human HepG2 whole cell, human Jurkat whole cell, human MCF-7 whole cell, human Caco-2 whole cell, rat heart tissue, mouse heart tissue, human A549 whole cell, human 293T whole cell, rat kidney tissue, mouse kidney tissue
Suggested blocking solution with 5% non-fat milk or BSA; (*)Recommended protein loading: 20-40 ug per lane
TIMM23 antibody was positively detected by IHC in:
human colon cancer tissue, human thyroid cancer tissue
Use TE buffer pH 9.0 for antigen retrieval; (*) citrate buffer pH 6.0 is an alternative.
Recommend Dilution
Application
Dilution
Species
Western blot
0.25-0.5 μg/ml
Human, Mouse, Rat
Immunohistochemistry(Paraffin-embedded Section)
2-5 μg/ml
Human
* It is recommended to optimize the amount of this reagent in each experimental system to achieve the best results.
Reactive Data
Filter:
Boster Guarantee:What is this?
WB
IHC
IF
Human
Tested
Tested
Recommend
Rat
Tested
Mouse
Tested
Product Information
Product Name
Anti-TIM23/TIMM23 Antibody Picoband®
View all TIMM23 Antibodies
View all TIMM23 Antibodies
Form
Lyophilized
Uniprot
Gene ID
Storage & Handling
At -20°C for one year from date of receipt.
After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months.
Avoid repeated freezing and thawing.
Host
Rabbit
Contents
Each vial contains 4 mg Trehalose, 0.9 mg NaCl, 0.2 mg Na2HPO4.
Clonality
Polyclonal
Immunogen
A synthetic peptide corresponding to a sequence in the middle region of human TIM23/TIMM23.
Reconstitution
Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.
Observed Molecular Weight
20 kDa
Calculated Molecular Weight
21.9 kDa
Background of TIMM23
The protein encoded by this gene is part of a complex located in the inner mitochondrial membrane that mediates the transport of transit peptide-containing proteins across the membrane. Multiple transcript variants, one protein-coding and others not protein-coding, have been found for this gene.
Cite This Product
Anti-TIM23/TIMM23 Antibody Picoband® (Boster Biological Technology, Pleasanton CA, USA, Catalog # A09218-1)
Protocols
Western Blot protocol for TIMM23 antibody
Immunohistochemistry (IHC) protocol for TIMM23 antibody
Publications
Application:
Species:
Subcellular Localization of Telomerase Reverse Transcriptase Regulates Gene-Specific Modulation of Mitochondrial DNA Copy Number in Neuronal Cells
Published: 2026-07-08
Journal: MOLECULAR NEUROBIOLOGY
Application: IF
Impact Factor: 5.50
Species: Mouse
PMID: 42420567
Neuroprotection and safety profile of Astragalus membranaceus extract TA-65 in neonatal hypoxic-ischemic brain damage by activating mitochondrial telomerase reverse transcriptase: Evidence from in vitro and in vivo studies
Published: 2025-05-31
Journal: JOURNAL OF ETHNOPHARMACOLOGY
Application: IF
Impact Factor: 5.40
Species: Mouse
PMID: 40456473
Review
Have you used Anti-TIM23/TIMM23 Antibody Picoband®?
Submit a review and receive $370 in product credits, a $185 Amazon gift card, or our carefully curated gift bundles.
Product Promise
We promise Anti-TIM23/TIMM23 Antibody Picoband® performs excellently in relevant applications for IHC, WB. If it doesn't perform as promised, we will refund the product. Learn more
In stock
Order Product
A09218-1
Buy one primary antibody get one 0.5ml HRP or Biotin secondary antibody for free.
*Sample sizes are prepared on demand and will take extra lead time. (cannot be conjugated)
$370.00
Troubleshooting
Boster Guarantee
Guaranteed product quality
We promise all of our products perform as described in datasheets.
This product is for Research Use Only. Not for use in diagnostic procedures.
