KIFC1 · Western blot design guide
KIFC1 Western Blot Planning Guide
Plan a KIFC1 Western blot around the catalog-observed 73.7 kDa band, image-backed A05325-1 evidence, HPA controls, and verified protocol records.
Evidence assembled July 2026 · For research use; verify linked source records and product datasheet before use
KIFC1 Western Blot Experimental Design Guide
Expected bands, validated protocols, controls and antibodies — the at-a-glance facts below, then the full design guide.
Must know before running
| Expected band | 73.7 kDa | |
| Observed band | Not reported — verify product WB image | |
| Gel | 12-15% | |
| Positive control | Testis | |
| Negative control | Hippocampus |
Important caveats
Reasons your observed band may differ from the expected size.
| ⓘ | Calculated mass | 73.7 kDa |
| ⓘ | Localization | Nucleus / Cytoplasm, cytoskeleton, microtubule organizing center, centrosome |
| ⓘ | Processing / PTM | Record-dependent |
| ⓘ | Reactivity | Human / Mouse / Rat |
Sample controls for KIFC1 Western blot
🧪Use Testis as the first positive-control candidate and Hippocampus as the HPA Not detected negative candidate.
Positive control: Testis (High)
Negative control: Hippocampus (Not detected)
HPA protein score determines control status; other expression data is supporting context only.
HPA tissue expression evidence for KIFC1
Comprehensive Human Protein Atlas IHC scoring per tissue. Rows are taken directly from the HPA tissue chart on each tissue page — click any row's HPA link to view the source.
Positive expression · recommended positive controls
| Tissue | Cell type | Level | Evidence | Source |
|---|---|---|---|---|
| Testis | Reported tissue cells | High | Protein (HPA) | HPA → |
| Skin | Reported tissue cells | Medium | Protein (HPA) | HPA → |
| Cervix | Reported tissue cells | Medium | Protein (HPA) | HPA → |
| Kidney | Reported tissue cells | Medium | Protein (HPA) | HPA → |
Section 1
What Is the Expected KIFC1 Western Blot Band Size?
Use the product-observed 73.7 kDa band as the primary planning value and retain the UniProt calculated mass as context.
| 73.7 kDa | Matches the authoritative product WB observation. |
| 73.7 kDa calculated | Use as UniProt context, not as a replacement observed band. |
| Unexpected additional signal | Do not assign identity without orthogonal positive/negative controls. |
💡Expected KIFC1 appearancePlan around 73.7 kDa and keep the calculated mass as supporting context.
| Catalog-observed band | 73.7 kDa; use this as the primary experimental expectation. |
| Calculated mass | 73.7 kDa from UniProt Q9BW19; retain as context. |
| Gel selection | 12-15%; shared with the recommended protocol and poster. |
| Specificity check | Compare the lead HPA positive and negative controls with A05325-1. |
| Situation | Likely cause | Next action |
|---|---|---|
| 73.7 kDa | Matches the authoritative product WB observation. | Confirm with orthogonal controls and the linked product record. |
| Additional band | May reflect processing, modification, or non-specific signal. | Run a dilution series and compare positive/negative controls. |
| Weak signal | Target abundance or transfer may be limiting. | Verify transfer, increase positive-control abundance, and bracket exposure. |
Experiment evidence
Western blot images showing KIFC1 band
A05325-1 · KIFC1Observed 73.7 kDa · product-specific WB image
← swipe / scroll for more images →
Real WB data behind the band-size expectations in this section.
Section 2
Real Curated KIFC1 Western Blot Protocols
Start with the molecular-weight rule, then compare verified publication-derived conditions.
| Sample / lysate | Testis |
| Gel % | 12-15% |
| Load | 20-30 µg total protein per lane |
| Transfer | Semi-dry, standard transfer |
| Membrane | 0.45 µm PVDF |
| Blocking | 5% non-fat milk or 5% BSA in TBST |
| Primary | A05325-1 at datasheet starting dilution |
| Primary incubation | Overnight at 4 °C with gentle agitation |
| Secondary | Species-matched HRP conjugate at validated dilution |
| Wash | 3 × 5 min in TBST |
| Detection | Chemiluminescent substrate |
| Exposure | Bracket exposures to avoid saturation |
Section 4
Advanced KIFC1 Western Blot Tips
Deeper troubleshooting and optimisation questions for KIFC1, answered from its protein features.
Which band should guide the blot?
Use 73.7 kDa, the observation attached to the authoritative A05325-1 WB record.
How should calculated mass be interpreted?
Treat the UniProt calculated mass as context; it does not replace the catalog-observed 73.7 kDa expectation.
Which positive control should I start with?
Start with Testis, the lead HPA protein-expression candidate.
Which negative control is defensible?
Use Hippocampus as an orthogonal HPA Not detected candidate.
Which gel should I use?
Use 12-15% consistently across the quick facts, protocol table, and poster.
What transfer method to use for KIFC1 Western blot?
Use the transfer method in the recommended protocol and verify transfer before blocking.
How should A05325-1 be started?
Start at the linked datasheet condition and run a three-point primary-antibody dilution test.
Which publication-derived protocols can I compare?
Compare only the supplied target-verified records: PMC7848269, PMC7894588, PMC6336682.
Boster reagents
KIFC1 Western Blot Reagents
Human/Mouse/Rat-reactive KIFC1 Western blot reagents with authoritative product imagery.
Real WB data
Anti-KIFC1 Antibody Picoband®
Cat # A05325-1
Reactivity: Human, Mouse, Rat
Only image-backed, WB-validated Human/Mouse/Rat recommendations from the prepared catalog evidence are shown.
Source: prepared picoband-wb product evidence; each card retains its own SKU, URL, observed band, and authoritative WB image.
References
- UniProt Q9BW19
- Human Protein Atlas — KIFC1
- A05325-1 product record
- PMC7848269 — Kinesin Motor Protein KIFC1 Is a Target Protein of miR-338-3p and Is Associated With Poor Prognosis and Progression of Renal Cell Carcinoma.
- PMC7894588 — Kinesin Family Member C1 Increases Temozolomide Resistance of Glioblastoma Through Promoting DNA Damage Repair.
- PMC6336682 — KIFC1 regulated by miR-532-3p promotes epithelial-to-mesenchymal transition and metastasis of hepatocellular carcinoma via gankyrin/AKT signaling.
