MEF2A · Western blot design guide
MEF2A Western Blot Planning Guide
Plan a MEF2A Western blot around the catalog-observed 54.8 kDa band, image-backed PB9953 evidence, HPA controls, and verified protocol records.
Evidence assembled July 2026 · For research use; verify linked source records and product datasheet before use
MEF2A Western Blot Experimental Design Guide
Expected bands, documented protocol parameters, controls and antibodies — the at-a-glance facts below, then the full design guide.
Must know before running
| Expected band | 54.8 kDa | |
| Observed band | Not reported — verify product WB image | |
| Gel | 12-15% | |
| Positive control | Adipose tissue | |
| Negative control | Liver |
Important caveats
Reasons your observed band may differ from the expected size.
| ⓘ | Calculated mass | 54.8 kDa |
| ⓘ | Localization | Nucleus |
| ⓘ | Processing / PTM | Record-dependent |
| ⓘ | Reactivity | Human / Mouse / Rat |
Section 1
Real Curated MEF2A Western Blot Protocols
Start with the molecular-weight rule, then compare verified publication-derived conditions.
| Sample / lysate | Adipose tissue |
| Gel % | 12-15% |
| Load | 20-30 µg total protein per lane |
| Transfer | Semi-dry, standard transfer |
| Membrane | 0.45 µm PVDF |
| Blocking | 5% non-fat milk or 5% BSA in TBST |
| Primary | PB9953 at datasheet starting dilution |
| Primary incubation | Overnight at 4 °C with gentle agitation |
| Secondary | Species-matched HRP conjugate at validated dilution |
| Wash | 3 × 5 min in TBST |
| Detection | Chemiluminescent substrate |
| Exposure | Bracket exposures to avoid saturation |
Section 2
What Is the Expected MEF2A Western Blot Band Size?
Use the product-observed 54.8 kDa band as the primary planning value and retain the UniProt calculated mass as context.
| 54.8 kDa | Matches the authoritative product WB observation. |
| 54.8 kDa calculated | Use as UniProt context, not as a replacement observed band. |
| Unexpected additional signal | Do not assign identity without orthogonal positive/negative controls. |
💡Expected MEF2A appearancePlan around 54.8 kDa and keep the calculated mass as supporting context.
| Catalog-observed band | 54.8 kDa; use this as the primary experimental expectation. |
| Calculated mass | 54.8 kDa from UniProt Q02078; retain as context. |
| Gel selection | 12-15%; shared with the recommended protocol and poster. |
| Specificity check | Compare the lead HPA positive and negative controls with PB9953. |
| Situation | Likely cause | Next action |
|---|---|---|
| 54.8 kDa | Matches the authoritative product WB observation. | Confirm with orthogonal controls and the linked product record. |
| Additional band | May reflect processing, modification, or non-specific signal. | Run a dilution series and compare positive/negative controls. |
| Weak signal | Target abundance or transfer may be limiting. | Verify transfer, increase positive-control abundance, and bracket exposure. |
Experiment evidence
Western blot images showing MEF2A band
PB9953 · MEF2A
← swipe / scroll for more images →
Real WB data behind the band-size expectations in this section.
Sample controls for MEF2A Western blot
🧪Use Adipose tissue as the first positive-control candidate and Liver as the HPA Not detected negative candidate.
Positive control: Adipose tissue (High)
Negative control: Liver (Not detected)
HPA protein score determines control status; other expression data is supporting context only.
HPA tissue expression evidence for MEF2A
Comprehensive Human Protein Atlas IHC scoring per tissue. Rows are taken directly from the HPA tissue chart — click any row's HPA link to view the source.
Positive expression · recommended positive controls
| Tissue | Cell type | Level | Evidence | Source |
|---|---|---|---|---|
| Adipose tissue | Reported tissue cells | High | Protein (HPA) | HPA → |
| Breast | Reported tissue cells | High | Protein (HPA) | HPA → |
| Cerebellum | Reported tissue cells | High | Protein (HPA) | HPA → |
| Adrenal gland | Reported tissue cells | High | Protein (HPA) | HPA → |
Section 3
Advanced MEF2A Western Blot Tips
Deeper troubleshooting and optimisation questions for MEF2A, answered from its protein features.
Which band should guide the blot?
Use 54.8 kDa, the observation attached to the authoritative PB9953 WB record.
How should calculated mass be interpreted?
Treat the UniProt calculated mass as context; it does not replace the catalog-observed 54.8 kDa expectation.
Which positive control should I start with?
Start with Adipose tissue, the lead HPA protein-expression candidate.
Which negative control is defensible?
Use Liver as an orthogonal HPA Not detected candidate.
Which gel should I use?
Use 12-15% consistently across the quick facts, protocol table, and poster.
What transfer method to use for MEF2A Western blot?
Use the transfer method in the recommended protocol and verify transfer before blocking.
How should PB9953 be started?
Start at the linked datasheet condition and run a three-point primary-antibody dilution test.
Which publication-derived protocols can I compare?
Compare only the supplied target-verified records: PMC13182153, PMC5058738.
Boster reagents
MEF2A Western Blot Reagents
Human/Mouse/Rat-reactive MEF2A Western blot reagents with authoritative product imagery.
Real WB data
Anti-MEF2A Antibody Picoband®
Cat # PB9953
Only image-backed, WB-validated Human/Mouse/Rat recommendations from the prepared catalog evidence are shown.
Source: prepared picoband-wb product evidence; each card retains its own SKU, URL, observed band, and authoritative WB image.
References
- UniProt Q02078
- Human Protein Atlas — MEF2A
- PB9953 product record
- PMC13182153 — MEF2A nuclear translocation mediated by ROCK phosphorylation promotes EZH2 expression and peritoneal fibrosis.
- PMC5058738 — Inhibition of myocyte-specific enhancer factor 2A improved diabetic cardiac fibrosis partially by regulating endothelial-to-mesenchymal transition.
