HLA-DRA antibody (M01195-4) performs well in Flow Cytometry, IHC, WB and shows reactivity with Human.
- Validated for inter-lot consistency, specificity, and reproducibility
- Committed to quality since 1993
Filter:
Flow Cytometry analysis of Daudi cells using anti-HLA-DRA antibody (M01195-4).
Overlay histogram showing Daudi cells stained with M01195-4 (Blue line). The cells were fixed with 4% paraformaldehyde and blocked with 10% normal goat serum. And then incubated with mouse anti-HLA-DRA Antibody (M01195-4, 1 μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-mouse IgG (BA1126, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was mouse IgG (1 μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Overlay histogram showing Daudi cells stained with M01195-4 (Blue line). The cells were fixed with 4% paraformaldehyde and blocked with 10% normal goat serum. And then incubated with mouse anti-HLA-DRA Antibody (M01195-4, 1 μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-mouse IgG (BA1126, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was mouse IgG (1 μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Bundle Save
Anti-HLA-DR/HLA-DRA Antibody Picoband® (monoclonal, 5B13F7)
HLA-DRA antibody
| Reactive Species | Host | Application |
|---|---|---|
| Human | Mouse | Flow Cytometry, IHC, WB |
Tested Applications
HLA-DRA antibody was positively detected by WB in:
human Raji whole cell, human Daudi whole cell
Suggested blocking solution with 5% non-fat milk or BSA; (*)Recommended protein loading: 20-40 ug per lane
HLA-DRA antibody was positively detected by IHC in:
human colonic adenocarcinoma tissue, human endometrial cancer tissue, human hepatocellular carcinoma tissue, human laryngeal squamous cell carcinoma tissue, human bladder epithelial carcinoma tissue
Use TE buffer pH 9.0 for antigen retrieval; (*) citrate buffer pH 6.0 is an alternative.
HLA-DRA antibody was positively detected by FC in:
Daudi cell
Recommend Dilution
Application
Dilution
Species
Western blot
0.25-0.5 μg/ml
Human
Immunohistochemistry(Paraffin-embedded Section)
2-5 μg/ml
Human
Flow Cytometry (Fixed)
1-3 μg/1x106 cells
Human
* It is recommended to optimize the amount of this reagent in each experimental system to achieve the best results.
Note: For flow cytometry (FCM), validated for fixed cells only. Not validated for FACS or surface flow cytometry using live cells.
Product Information
Product Name
Anti-HLA-DR/HLA-DRA Antibody Picoband® (monoclonal, 5B13F7)
View all HLA-DRA Antibodies
View all HLA-DRA Antibodies
Form
Lyophilized
Uniprot
Gene ID
Storage & Handling
At -20°C for one year from date of receipt. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months. Avoid repeated freezing and thawing.
Host
Mouse
Contents
Each vial contains 4 mg Trehalose, 0.9 mg NaCl and 0.2 mg Na2HPO4.
Clonality
Monoclonal
Clone Number
5B13F7
Isotype
Mouse IgG2b
Immunogen
E.coli-derived human HLA-DR/HLA-DRA recombinant protein (Position: I26-L254).
Cross-Reactivity
No cross-reactivity with other proteins.
Reconstitution
Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.
Observed Molecular Weight
35-37 kDa
Calculated Molecular Weight
28.6 kDa
Background of HLA-DRA
HLA class II histocompatibility antigen, DR alpha chainis aproteinthat in humans is encoded by the HLA-DRAgene. It is mapped to 6p21.32. HLA-DRA is one of the HLA class II alpha chain paralogues. This class II molecule is a heterodimer consisting of an alpha and a beta chain, both anchored in the membrane. It plays a central role in the immune system by presenting peptides derived from extracellular proteins. Class II molecules are expressed in antigen presenting cells (APC: B lymphocytes, dendritic cells, macrophages). The alpha chain is approximately 33-35 kDa and its gene contains 5 exons. Exon 1 encodes the leader peptide, exons 2 and 3 encode the two extracellular domains, and exon 4 encodes the transmembrane domain and the cytoplasmic tail. DRA does not have polymorphisms in the peptide binding part and acts as the sole alpha chain for DRB1, DRB3, DRB4 and DRB5.
Cite This Product
Anti-HLA-DR/HLA-DRA Antibody Picoband® (monoclonal, 5B13F7) (Boster Biological Technology, Pleasanton CA, USA, Catalog # M01195-4)
Antibody Homology Across Species
The results generated by this homology analysis tool for commonly used animal species are shown below. For unlisted species, please refer to the homology analysis between the immunogen sequence and the corresponding species.
A homology of ≥90% is recommended. Generally, higher homology indicates a greater potential for cross-species reactivity. However, protein expression levels may vary among different species, tissues, and cell types. Therefore, the homology analysis results are for reference only and do not guarantee antibody cross-reactivity or experimental performance.
Human
100%
High Homology
Dog
88%
Moderate Homology
Rabbit
85%
Moderate Homology
Rat
79%
Moderate Homology
Homology ≥ 90%High Homology
70% ≤ Homology < 90%Moderate Homology
Homology < 70%Low homology
Protocols
Western Blot protocol for HLA-DRA antibody
Immunohistochemistry (IHC) protocol for HLA-DRA antibody
Flow Cytometry (FC) protocol for HLA-DRA antibody
Review
Have you used Anti-HLA-DR/HLA-DRA Antibody Picoband® (monoclonal, 5B13F7)?
Submit a review and receive $370 in product credits, a $185 Amazon gift card, or our carefully curated gift bundles.
Product Promise
We promise Anti-HLA-DR/HLA-DRA Antibody Picoband® (monoclonal, 5B13F7) performs excellently in relevant applications for Flow Cytometry, IHC, WB. If it doesn't perform as promised, we will refund the product. Learn more
In stock
Order Product
M01195-4
Buy one primary antibody get one 0.5ml HRP or Biotin secondary antibody for free.
*Sample sizes are prepared on demand and will take extra lead time. (cannot be conjugated)
$370.00
Troubleshooting
Boster Guarantee
Guaranteed product quality
We promise all of our products perform as described in datasheets.
This product is for Research Use Only. Not for use in diagnostic procedures.
