Anti-RAGE/AGER Antibody Picoband™

Product Name

Anti-RAGE/AGER Antibody Picoband™

View all AGER Antibodies

SKU/Catalog Number

A03438-1

Size

100 μg/vial

Form

Lyophilized

Description

Boster Bio Anti-RAGE/AGER Antibody Picoband™ catalog # A03438-1. Tested in ELISA, Flow Cytometry, IF, IHC, ICC, WB applications. This antibody reacts with Human, Mouse, Rat.

Storage & Handling

At -20°C for one year from date of receipt. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months. Avoid repeated freezing and thawing.

Cite This Product

Anti-RAGE/AGER Antibody Picoband™ (Boster Biological Technology, Pleasanton CA, USA, Catalog # A03438-1)

Host

Rabbit

Contents

Each vial contains 4 mg Trehalose, 0.9 mg NaCl, 0.2 mg Na2HPO4.

Clonality

Polyclonal

Isotype

Rabbit IgG

Immunogen

E.coli-derived human RAGE/AGER recombinant protein (Position: K43-P404).

*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.

Cross-reactivity

No cross-reactivity with other proteins.

Reactive Species

A03438-1 is reactive to AGER in Human, Mouse, Rat

Applications

A03438-1 is guaranteed for ELISA, Flow Cytometry, IF, IHC, ICC, WB Boster Guarantee

Observed Molecular Weight

45-58 kDa

Calculated molecular weight

42.803kDa

Background of AGER

The receptor for advanced glycation end products (RAGE) is a multi-ligand member of the immunoglobulin superfamily of cell surface molecules. It interacts with distinct molecules implicated in homeostasis, development and inflammation, and certain diseases such as diabetes and Alzheimer's disease. RAGE is also a central cell surface receptor for amphoterin and EN-RAGE. And RAGE is associated with sustained NF-kappaB activation in the diabetic microenvironment and has a central role in sensory neuronal dysfunction. Moreover, RAGE propagates cellular dysfunction in several inflammatory disorders and diabetes, and it also functions as an endothelial adhesion receptor promoting leukocyte recruitment.

Antibody Validation

Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.

View more details

Reconsitution

Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.

Assay Dilutions Recommendation

The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.

Western blot, 0.25-0.5 μg/ml, Mouse, Rat
Immunohistochemistry(Paraffin-embedded Section), 2-5 μg/ml, Rat
Immunocytochemistry/Immunofluorescence, 5 μg/ml, Human
Flow Cytometry, 1-3 μg/1x10⁶ cells, Human
Direct ELISA, 0.1-0.5 μg/ml, Human

Validation Images & Assay Conditions

Click image to see more details

Figure 1. Western blot analysis of RAGE/AGER using anti-RAGE/AGER antibody (A03438-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: rat lung tissue lysates,
Lane 2: mouse lung tissue lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-RAGE/AGER antigen affinity purified polyclonal antibody (Catalog # A03438-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for RAGE/AGER at approximately 45-58 kDa. The expected band size for RAGE/AGER is at 43 kDa.

Click image to see more details

Figure 2. IHC analysis of RAGE/AGER using anti-RAGE/AGER antibody (A03438-1).
RAGE/AGER was detected in a paraffin-embedded section of rat lung tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml rabbit anti-RAGE/AGER Antibody (A03438-1) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.

Click image to see more details

Figure 3. IF analysis of RAGE/AGER using anti-RAGE/AGER antibody (A03438-1).
RAGE/AGER was detected in an immunocytochemical section of MCF-7 cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 5 μg/mL rabbit anti-RAGE/AGER Antibody (A03438-1) overnight at 4°C. DyLight®488 Conjugated Goat Anti-Rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution and incubated for 30 minutes at 37°C. The section was counterstained with DAPI. Visualize using a fluorescence microscope and filter sets appropriate for the label used.

Click image to see more details

Figure 4. Flow Cytometry analysis of MCF-7 cells using anti-RAGE/AGER antibody (A03438-1).
Overlay histogram showing MCF-7 cells stained with A03438-1 (Blue line). The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-RAGE/AGER Antibody (A03438-1, 1 μg/1x10⁶ cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10 μg/1x10⁶ cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1 μg/1x10⁶) used under the same conditions. Unlabelled sample (Red line) was also used as a control.

Gene/Protein Information For AGER (Source: Uniprot.org, NCBI)

Alternative Names

advanced glycosylation end product-specific receptor; AGER; RAGE isoform delta; RAGE isoform sRAGE-delta; RAGE; Receptor for advanced glycosylation end products; receptor for advanced glycosylation end-products; SCARJ1 AGER RAGE, SCARJ1, sRAGE advanced glycosylation end-product specific receptor advanced glycosylation end product-specific receptor|receptor for advanced glycation end-products variant 20

For more info on AGER, check out the AGER Infographic

We have 30,000+ of these available, one for each gene! Check them out.

In this infographic, you will see the following information for AGER: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].

Take me to the AGER Infographic
